ROHO AGILITY - Parts Detail

- 4 -
PARTS DETAIL
Package Contents:
Hand PumpRepair Kit Lumbar Support Pad
Additional Package Contents depending on model:
Note: A tape measure or ruler is recommended, but not
included in the package contents.
1 65432
Dual Wrench Detail - To separate and assemble for use as an Allen Wrench:
Upper Pin
Back Cane Bracket
(Right (
R
), Standard
shown)
Lower Pin
Back Cane
Hardware Bolt
Adjustment
Cylinder
Back Cane Hardware Detail - Right (
R
), Standard shown:
Pivoting
Back Cane
Band
Triangle
Bracket
Width and Height
Adjustment Nut
Latch
Back Shell Hardware Detail - Right (R) shown:
Depth
and Angle
Adjustment
Bolt
Double Hook -
Right (R)
shown
Safety Lock
Sliding
Height
Adjustment
Bar
(on front side
of back shell)
Width and
Height
Adjustment
Bolt
Width and
Height
Adjustment Bolt
Width and Height
Adjustment Nut
Cover
(See Detail)
Back Shell
Back Shell
Hardware (R)
(See Detail)
Registration Card
Product
Registration Card
Operation Manual
ROHO
®
AGILITY
™
Back Systems
OPERATION MANUAL
SUPPLIER: This manual must be given to the user of this product.
USER: Before using this product, read instructions and save for
future reference.
shape fitting technology
®
Dual Wrench (See Detail)
(4 mm Hex Key)
(10 mm Box End)
Back Shell Hardware (L)
Back Cane Hardware (See Detail)
L
R
