ROHO AGILITY - Cover Removal and Installation; Cover Components - Removal and Installation

- 13 -
COVER COMPONENTS - REMOVAL
Beginning at the wide end, pull the cover
away from the back shell releasing it from
the fastener strips on the front side of the
back shell.
On the back side of the back shell’s wide end,
release the fastener strips between the cover
flap and the back shell.
Flip the cover completely over the narrow end
of back shell.
On the front of the back shell’s narrow end,
release the fastener strips between the cover
flap and the back shell.
Pull the flap from the horizontal slot in the
back shell.
COVER REMOVAL AND INSTALLATION
TO REMOVE THE COVER:
TO REMOVE THE FOAM PAD, AIR INSERT OR FOAM INSERT:
WARNING: DO NOT remove or install the AGILITY cover with the individual in the chair.
DO NOT use the AGILITY without the cover, foam pad, and, if applicable, the air insert or foam insert, in place.
1 2
TO INSTALL THE COVER:
3
1. Unzip the cover.
2. Remove the foam pad from inside the cover with the air insert or foam insert, if applicable, still attached.
3. Detach the insert from the fastener strip in the cutout area of the foam pad.
4. If the air insert attached, pull the valve hose back through the hole in the foam pad.
From the back side of the back shell, push
the flap through the horizontal slot on back
shell’s narrow end.
Press fastener strips on the flap and back
shell together.
Flip the cover over the narrow end of the back
shell.
Make sure the zipper side of the cover is
toward the back shell.
Secure the back side of the cover to the
fastener strips on the front side of the back
shell.
Pull the wide end of the cover over the wide
edge of the back shell.
Press the fastener strips on the cover flap and
back shell’s wide end together.
1 2 3
