ROHO AGILITY - Page 8

- 6 -
PRODUCT SPECIFICATIONS* CONTINUED
AGILITY HEIGHT (H) ADJUSTABLE AIR INSERT HEIGHT
in. (cm) in. (cm) # Cells
10.0 (25.5) 6.5 (16.5) 3
13.0 (33.0) 10.5 (27.0) 5
16.0 (40.5) 12.5 (32.0) 6
18.0 (45.5) 14.5 (37.0) 7
20.0 (51.0) 16.5 (42.0) 8
Height (H) measurements are
taken from center edge to center
edge between the narrow and
wide ends of the back shell.
Note: Cover assembly not
included in height measurement.
All air inserts:
• Width: 3 cells, 6.5 in. (16.5 cm)
• Perimeter: 0.25 in. (1.0 cm) included in height
and width measurements
• Cell height: 1.25 in. (3.0 cm) when fully inflated
W
H
*NOTE: All measurements are approximate.
AGILITY
WIDTH (W)
ADJUSTS TO FIT WHEELCHAIR WIDTHS
Smallest** Largest
in. (cm) in. (cm) in. (cm)
14.0 (35.5) 13.0 (33.0) 14.0 (35.5)
16.0 (40.5) 15.0 (38.0) 16.0 (40.5)
18.0 (45.5) 17.0 (43.0) 18.0 (45.5)
20.0 (51.0) 19.0 (48.5) 20.0 (51.0)
Width (W) measurements are taken from the outside of the back cane to the outside of the back cane.
**There will be a 0.5 in. (1.5 cm) loss of seat depth if an AGILITY is fitted to the smallest wheelchair width within each size range.
AGILITY DEPTH (D) AND WEIGHT RANGE
AGILITY Model
Depths and weights are based on (W x H): 14 in. x 10 in. (35.5 cm x 25.5 cm), 16 in. x 16 in. (40.5 cm x 40.5 cm),
and 20 in. x 18 in. (51.0 cm x 45.5 cm) AGILITY Minimum Contour models. 14 in. x 10 in. (35.5 cm x 25.5 cm),
16 in. x 16 in. (40.5 cm x 40.5 cm), and 20 in. x 20 in. (51.0 cm x 51.0 cm) AGILITY Mid Contour models.
Least Average Greatest
DEPTH
Depth (D) measurements are taken from the highest point of a contoured edge of the cover to the center,
front surface of a cover assembled with an air insert inflated to allow 0.5 in. (2.5 cm) immersion. Depth of
foam only models will be 0.5 in. (2.5 cm) less.
in. (cm) in. (cm) in. (cm)
AGILITY Minimum Contour
3.0 (7.5) 3.0 (7.5) 3.5 (9.0)
AGILITY Mid Contour
3.75 (9.0) 4.0 (10.0) 4.25 (11.0)
WEIGHT
Weight ranges do not include Back Cane Hardware. Pair of Back Cane Hardware with Standard Bracket:
0.75 lbs. (0.30 kg)
lbs. (kg) lbs. (kg) lbs. (kg)
AGILITY Minimum Contour 2.5 (1.1) 4.0 (1.8) 5.25 (2.3)
AGILITY Mid Contour 2.5 (1.2) 4.25 (1.9) 6.0 (2.8)
D
