Getting Ready
Connecting an Amp and Speaker System
Since the Fantom contains no amplifier or speakers, you’ll need to connect it to audio
equipment such as a keyboard amplifier, monitor speaker system or home stereo, or
use headphones to hear its sound.
1
Before hooking anything up, make sure that the power on all of your
gear is turned OFF.
2
Connect one end of the supplied power cable to the Fantom, and the
other end to a power outlet.
3
Connect the Fantom to your amp/speaker system as shown in the
diagram.
fig.Q-01.e
Use audio cables to connect audio equipment such as an amp or speakers. If you’re
using headphones, plug them into the PHONES jack.
To prevent malfunction and/
or damage to speakers or other
devices, always turn down the
volume, and turn off the
power on all devices before
making any connections.
Monitor speakers
(powered)
Power amp
Mixer etc.
Stereo headphones
to Power outlet
In order to fully experience the
Fantom’s sound, we
recommend using a stereo
amp/speaker system. If you’re
using a mono system,
however, make your
connections to the Fantom’s
OUTPUT A (MIX) jack L
(MONO).
Audio cables are not included
with the Fantom. You’ll need
to provide them.
For details on how to install a
Wave Expansion Board (sold
separately), refer to “Installing
the Wave Expansion Board”
(Owner’s Manual; p. 196).
To Next Page
