Roland S-1 User Manual

Creating sounds
14
Chopping a waveform and emphasizing its harmonics (OSC CHOP)
Ø Chopping a waveform and emphasizing its harmonics (OSC CHOP)(P.31)
[LFO] knob
This knob adjusts the modulation intensity, when you use the modulator signal from the LFO section to control the fundamental
frequency (pitch) of the OSC.
The method of change depends on the setting of the [WAVE FORM] knob in the LFO section.
Mixing the output from the oscillator (source mixer)
Four waveforms are always output from the OSC, and you can mix their levels in the ratio you like. The source mixer output is sent
to the FILTER section.
Controller
Explanation
[ (square wave)] knob
Adjusts the level of the square wave or the original waveform you create using OSC DRAW.
[ (sawtooth wave)] knob
Adjusts the level of the sawtooth wave.
[SUB] knob
Adjusts the level of the sub oscillator.
[NOISE] knob
Adjusts the level of the noise.
Selecting the output waveform for the sub-oscillator (SUB OCT)
This shows how to select the sub-oscillator output waveform.
1. Hold down the [SHIFT] button and press the [SUB OCT] pad.
2. Turn the [TEMPO/VALUE] knob to edit the value.
Value
Explanation
-2o.A
-2 octave asymmetrical waveform
-2oc
-2 octave symmetrical waveform
-1oc
-1 octave symmetrical waveform
Selecting a noise output waveform (Noise Mode)
Here’s how to select the noise output waveform.
1. Hold down the [SHIFT] button and press pad [15] (MENU).
2. Use the [TEMPO/VALUE] knob to select “nS.Nd” (Noise Mode), and press pad [2] (ENTER).
3. Turn the [TEMPO/VALUE] knob to edit the value.
Value
Explanation
Pink
Pink noise
ľhit
White noise

Roland S-1 Specifications

General

Product type	Digital synthesizer
Product color	Black, Blue
Sound effects	Delay, Reverberation
Keyboard number of keys	-
DC-in jack	Yes
Input voltage	9 V
Power source type	AC, Battery

Weight and Dimensions

Depth	129 mm
Width	73 mm
Height	59 mm
Weight	450 g
