Roland System-8 Reference Manual

34
Using the Vocoder (VOCODER)
When the PerfMode Is “SINGLE”
When the PerfMode (p. 14) is set to "SINGLE," operation is as follows.
5 When you turn the [VOCODER] button "on,"
The input (Microphone) audio is not output.
The audio of the upper part and lower part patches is not output.
DELAY
CHORUS
REVERB
[VOCODER]
button
PART
ON/OFF
[UPPER]
[LOWER]
Button
VOCODER
OUTPUT
INPUT
PERFORMANCE MODE
SYSTEM setting
INPUT: Gain
PEAK LED
PERF EDIT
INPUT (Voc): Carrier
[INPUT]
knob
LOWER PART
PATCH
UPPER PART
PATCH

Roland System-8 Specifications

General

Product type	Digital synthesizer
Product color	Black
Keyboard number of keys	49
Maximum polyphony (notes)	8
Display type	LCD
Built-in display	Yes
Display number of characters	16
USB ports quantity	1
Compatible memory cards	SD, SDHC
Power source type	DC

Weight and Dimensions

Depth	364 mm
Width	881 mm
Height	109 mm
Weight	5900 g
