4. Assembly and Ink Filling
Checks before Operations
CAUTION
Unpacking and installation must be carried out by six or more people.
Failure to observe this instruction may cause the machine to fall over, resulting
in injury.
Completed Drawing
Necessary Tools
Included items
Commercially
available item
Hexagonal wrench
(large)
Pipe
* Spanner Phillips screwdriver
* If the hexagonal wrenches are too small and it is dicult to tighten the bolts, you may need to use the
pipe to increase the length of the wrench.
How to view pictures
When tightening the bolts fully, tighten them securely. Loose bolts may cause the stand to
wobble.
Tighten temporarily
Tighten fully
