4. Assembly and Ink Filling
14
Step 2: Attaching the Machine
Procedure
Place the machine on the stand.
Arrange the stand so that the bent side of the tabletop plates ( ) are to the back.
Tighten the bolts in the two locations on the back and then in the two locations on the
bottom in the order of
, to secure the machine to the stand
First tighten the bolts temporarily in the order of and then , and then tighten the bolts fully in
the same order.
Tighten
temporarily
Bolts: 8
Washers (silver): 8
Tighten
fully
To Next Page
