4. Assembly and Ink Filling
24
Step 6: Removing the Retainers
Procedure
Remove the retainers indicated by and .
Install the retainer indicated by at the position indicated in the gure for storage.
Make sure to remove the retainers. If it remains on the machine, faulty operation or breakdown
may occur when the power is switched on.
Store the retainers because they are needed again when transporting the machine.
To Next Page
