4. Assembly and Ink Filling
25
Step 7: Installing the Ink System
About this procedure
This procedure must be performed by a suitably qualied service technician. Never attempt to perform this
procedure yourself.
CAUTION
Leave this work to a suitably qualied worker.
This procedure includes work near sources of electrical danger and complex
assembly work. Incorrect work may result in injury and mechanical malfunction.
Items used in this procedure
Roland Ink System
1 set
Printer unit included items
Tube caps
Cleaning sticks
Step 8: Connecting the Cables and Making Initial Settings
1.
Connect the cables.
Insert the cable clamp.
Cable clamp
