4. Assembly and Ink Filling
21
Tighten the bolts in 2 locations to secure the feed adjuster stays.
Attach the bolts removed in step
together with the feed adjuster stays to the machine. (Do not use
the washers removed in step
.)
w
Tighten the bolts in 4 locations to secure the feed adjusters.
There are four attachment holes in the feed adjuster stays. Use the front hole and the third hole from
the front.
Tighten fully
Bolts: 4
Tighten fully
Bolts: 4
To Next Page
