Controller functions
UPT-640 (as of SW 100) 29
9.5 Two-digit numbering system
up to software revision 022
A system of one and two-digit numbers was used for
the Settings and Configuration menus up to software
revision 022. Three-digit numbers were introduced in
software revision 100 to improve the clarity of the menu
structure.
The table below compares the two numbering systems:
All numbers or menu steps not listed above
are only available as of software revision 100
and are described in chap. 8 „Startup and opera-
tion“, page 17 (and section 9.4 "Menu structure" on
page 27 respectively).
Menu Menu steps
Numbering
up to software
revision 022
Numbering
as of software
revision 100
Settings menu Heatsealing temperature 2 101
Starting delay 3 103
Heatsealing time 3 104
Cooling value 4 105
Hold mode 5 106
AUTOCAL 1 107
Correction factor Co 6 110
Release temperature 10 115
Release delay 11 116
Release duration 12 117
Configuration menu Language 30 201
Factory settings 31 202
Alloy / TCR 32 203, 204
Maximim temperature 33 206
Set point reached 35 207
Set point exceeded 36 208
Time control 37 209
Cooling mode 38 210
Relay K1 function 39 212
Cycles 42 214
Alarm relay 43 215
Analog output 34 216
Starting temperature 40 224
No longer available
menus
Cycle configuration 20 ---
Hand impulse 21 ---
