Orion Installation and Operations Manual
31
Switching using a Browser / Web Interface
The Web Interface is under development.
In Browser mode, switching will be designed to perform similarly to the Switching in OSD / Crosspoint Mode.
Similar masks are generated and displayed.
Switching using a Serial Interface
The Orion™ provides full Crosspoint switching functionality via Serial Interface.
Serial switching commands allow switching of video only, K/M only and bidirectional switching. Additional
Commands allow loading, saving and defining the complete switch matrix in one step.
All available serial switching commands are listed in Appendix D: Serial Interface.
