46
Orion Installation and Operations Manual
Telegrams, Switching functions Console (“Video signal“)
No
Function
Telegram
Reply
1
CON# Output Signal from CPU#
STX, 0x47, <CON#>,
<CPU#>, ETX
ACK, ECHO
2
CON# Output off
STX, 0x48,
<CON#>, ETX
ACK, ECHO
3
CON01…CON16
Output Signal from
CPU#1…CPU#16, resp.
• requires 16 CPU#
• 0x80 for
“No Output“
STX, 0x49,
<CPU#1>,
<CPU#2>,
…,
<CPU#16>,
ETX
ACK, ECHO
4
All CON Ports Output off
STX, 0x4A, ETX
ACK, ECHO
Telegrams, Switching functions CPU (K/M-“Return Channel“)
No
Function
Telegram
Reply
5
CPU# Output Signal
from CON#
STX, 0x4B,
<CPU#>,
<CON#>, ETX
ACK, ECHO
6
CPU# Output off
STX, 0x4C,
<CPU#>, ETX
ACK, ECHO
7
CPU01…CPU32
Output Signal from
CON#1…CON#32,
resp.
• requires 32 CON#
• 0x80 for
“No Output“
Attention: only 16
CON Ports available,
requires 16x 0x80!
STX, 0x4D,
<CON#1>,
<CON#2>,
…,
<CON#32>,
ETX
ACK, ECHO
8
All CPU Ports Output off
STX, 0x4E, ETX
ACK, ECHO
9
Establish Bidi-
Connection
CON# ⇔ CPU#
STX, 0x4F,
<CON#>,
<CPU#>, ETX
ACK, ECHO
10
Disconnect CON#
STX, 0x50,
<CON#>, ETX
ACK, ECHO
