4-3
MODEL 54 C SECTION 4
CALIBRATION
F. When the temperature and sensor have stabilized at the first tem-
perature enter the conductivity reading from B above and press
Enter (F4).
G. Adjust the sample’s temperature to the other normal temperature
extreme of the process.
H. Enter the conductivity reading from B above at the second tem-
perature and press Enter (F4).
I. The temperature slope will display. Press Enter (F4) and standard-
ize sensor.
5. The analyzer compensates for differences in cable resistance by
measuring a reading while the sensor is in air (which has zero
conductivity).
Slope: 2.00%/°C
Temperature slope
calibration complete
Exit Enter
Sensor zero:
Sensor must be in air
Exit Enter
