MODEL 54 C SECTION 8
DESCRIPTION AND ORDERING INFORMATION
8-3
8.3 ORDERING INFORMATION
The Model 54 Conductivity Microprocessor Analyzer is housed in a rugged, NEMA 4X (IP65) epoxy painted
cast aluminum enclosure and is compatible with both contacting and inductive conductivity sensors. Standard
features include a dot-matrix liquid crystal display, dual isolated outputs, three process alarms with independ-
ent setpoints and a fault alarm.
ACCESSORIES
PART NO. DESCRIPTION
23554-00 Cable glands, kit (Qty 5 of PG 13.5)
2002577 Mounting bracket, 2 in., pipe or wall
23545-00 Panel mounting kit
9240048-00 S.S. Tag (specify marking)
CODE OPTIONS
08 115/230Vac, 50/60Hz power, CE
MODEL
54 C MICROPROCESSOR ANALYZER
CONTACTING SENSORS
Conductivity Sensor 142 142 140 140, 141 401-14
Model Number 400 150 141 150 150 402/403
402/403 400/402/403 400/402/403
Cell Constant 0.01 0.1 0.2 0.5 1.0 10.0
Minimum Range 1 2 4 100 200 2000
Maximum Range 200 2,000 4,000 10,000 20,000 200,000
FULL SCALE MICROSIEMENS/cm
FULL SCALE MICROSIEMENS/cm
INDUCTIVE SENSORS
Conductivity Sensor
Model Number 226 228 225 222 (1in.) 222 (2 in.)
Cell Constant* 1.0 3.0 3.0 6.0 4.0
Minimum Range 50 250 250 500 500
Maximum Range 1,000,000 2,000,000 2,000,000 2,000,000 2,000,000
* Typical
54 C — 08 EXAMPLE
