7
MODEL 1054B pH/ORP SECTION 2.0
INSTALLATION
FIGURE 2-3. Wall Mounting J-Box Installation
DWG. NO. REV.
41054A27 A
ITEM PART NUMBER DESCRIPTION QUANTITY
1 23058-01 S Assy, J-Box 1
2 33030-00 Bracket, wall mtg 1
3 9900600 Nut, 6-32 Hex 4
4 9910600 Washer, Flat #6 4
5 9910610 Washer, Lock Int. #6 8
6 9600612 Screw, 6-32 X .75 4
7 9510048 Seal, Weathertight 1
