22
MODEL 1054B pH/ORP SECTION 4.0
CONFIGURATION
RANGE FACTORY SET USER SET
A. Alarm 1 Setup (AL1)
1. Alarm Status (On/OFF) On _________
2. High or Low (H-L)(Hi/ Lo) Lo _________
3. Hysteresis (HYS) 0-25% of setpoint 0.0% _________
4. Delay Time On (don) 0-255 sec. 000 Seconds _________
5. Delay Time Off (doF) 0-255 sec. 000 Seconds _________
B. Alarm 2 Setup (AL2)
1. Alarm Status (On/ FLt/ OFF) On _________
2. High or Low (H-L)(Hi/ Lo) Hi _________
3. Hysteresis (HYS) 0-25% of setpoint 0.0% _________
4. Delay Time On (don) 0-255 sec. 000 Seconds _________
5. Delay Time Off (doF) 0-255 sec. 000 Seconds _________
C. Interval Timer (Int)
1. Active Status (tOn)(oFF/ on) oFF _________
2. Interval Time (int) minimum 10 minutes 1 Day _________
3. Count (Cnt) 1 to 60 5 _________
4. On Time (Ont) 0 to 299.9 sec 1 Second _________
5. Off Time (OFt) 0 to 299.9 sec 1 Second _________
6. Duration (dur) 0 to 299.9 sec 2 Seconds _________
D. Temperature Setup (t-c)
1. Display Temperature (d-t)(
o
C/
o
F) °C _________
2. Automatic (t-C)(Atc)(on/ oFF) On _________
E. Current Output Setup ((OUt)
1. mA Output (CUr)(020/ 420) 420 _________
2. Display Current Output (d-O)(Pct/ doc) doc _________
3. Dampen Current Output (dPn) 0-255 sec. 0.0 Seconds _________
F. Displays Convention
1. U.S. (Or)/European (rO) Or __________
G. Default Setup (dFt)
1. Relay 1 Default (rL1)(non/ oFF/ on) non _________
2. Relay 2 Default (rL2)(non/ oFF/ on) non _________
3. Current Output Default (Cur)(non/ cur) non _________
H. Keyboard Security Setup
1. Keyboard Security Required 001-999 _ _________
2. Keyboard Security Not Required 000 000 _________
Alarm Set Points
1. Alarm 1 (SP1) -1500 - +1500 mV -1500 mV _________
2. Alarm 2 (SP2) -1500 - +1500 mV +1500 mV _________
Current Output
1. Zero (0 or 4 mA) -1500 - +1500 mV -1500 mV _________
2. F.S. (20 mA) -1500 - +1500 mV +1500 mV _________
TABLE 4-2. Configuration Worksheet (ORP)
Use this work sheet to assist in the configuration of the analyzer. Date: ____________________
