Rosemount 1495 - Page 24

Reference Manual
00809-0100-4792, Rev CA
August 2010
3-12
Rosemount 1495, 1496
Line Size
Flange Rating 2 in. (50 mm) 2.5 in.(64 mm) 3 in. (80 mm) 4 in.(100 mm) 6 in.(150 mm) 8 in.(200 mm) 10 in.(250 mm)
ANSI Thickness = 0.250 in. (6.32 mm)
A3 ANSI Class 300 1.37(0.62) 1.78(0.81) 2.25(1.02) 3.17(1.44) 5.82(2.64) 8.99(4.08) 12.17(5.52)
A6 ANSI Class 600 1.37(0.62) 1.78(0.81) 2.25(1.02) 3.59(1.63) 6.54(2.97) 9.70(4.40) 14.73(6.68)
A6 ANSI Class 900 2.08(0.94) 2.68(1.22) 2.78(1.26) 4.03(1.83) 7.63(3.46) 11.97(5.43) 17.29(7.84)
AF ANSI Class 1500 2.08(0.94) 2.68(1.22) 2.97(1.35) 4.15(1.88) 7.31(3.32) 11.57(5.25) 17.29(7.84)
AT ANSI Class 2500 2.16(0.98) 2.78(1.26) 3.69(1.68) 5.14(2.33) 9.16(4.15) 13.85(6.28) 20.60(9.34)
DIN Thickness = 0.118 in. (3.0 mm)
D1 DIN PN10 0.80(0.36) 0.99(0.45) 1.16(0.53) 1.41(0.64) 2.30(1.04) 3.41(1.55) 4.49(2.17)
D2 DIN PN16 0.80(0.36) 0.99(0.45) 1.16(0.53) 1.41(0.64) 2.30(1.04) 3.41(1.55) 4.82(2.19)
D3 DIN PN25 0.80(0.36) 0.99(0.45) 1.16(0.53) 1.49(0.68) 2.41(1.09) 3.67(1.67) 5.13(2.33)
D4 DIN PN40 0.80(0.36) 0.99(0.45) 1.16(0.53) 1.49(0.68) 2.41(1.09) 3.82(1.73) 5.47(2.48)
D5 DIN PN63 0.85(0.39) 1.11(0.50) 1.23(0.56) 1.58(0.72) 2.86(1.30) 4.29(1.95) 5.83(2.64)
D6 DIN PN100 0.91(0.41) 1.18(0.54) 1.31(0.59) 1.67(0.76) 3.07(1.39) 4.69(2.13) 6.67(3.03)
Line Size
Flange Rating 12 in.(300 mm) 14 in.(350 mm) 16 in.(400 mm) 18 in.(450 mm) 20 in.(500 mm) 24 in.(600 mm)
ANSI Thickness = 0.250 in. (6.32 mm)
A3 ANSI Class 300 16.33(7.41) 21.41(9.71) 26.28(11.92) 31.66(14.36) 37.91(17.20) 53.01(24.04)
A6 ANSI Class 600 19.04(8.63) 10.80(4.90) 28.74(13.04) 33.34(15.12) 41.26(18.71) 55.19(25.03)
A6 ANSI Class 900 22.51(10.21) 24.50(11.11) 29.70(13.47) 36.12(16.38) 43.18(19.58) 61.98(28.11)
AF ANSI Class 1500 24.50(11.11) 30.02(13.62) 36.83(16.71) 43.96(19.94) 50.46(22.89) 72.17(32.73)
AT ANSI Class 2500 27.19(12.33) N/A N/A N/A N/A N/A
DIN Thickness = 0.118 in. (3.0 mm)
D1 DIN PN10 6.26(2.84) 8.29(3.76) 10.26(4.65) 12.39(5.62) 15.08(6.84) 20.48(9.29)
D2 DIN PN16 6.44(2.92) 8.51(3.86) 10.51(4.77) 13.12(5.95) 16.23(7.36) 22.80(10.34)
D3 DIN PN25 6.97(3.16) 9.00(4.08) 11.31(5.13) 13.58(6.16) 16.59(7.53) 22.62(10.26)
D4 DIN PN40 7.55(3.43) 9.66(4.38) 12.70(5.76) 13.87(6.29) 16.79(7.62) 23.60(10.70)
D5 DIN PN63 7.79(3.53) 10.13(4.60) 12.58(5.71) N/A 18.35(8.32) 24.67(11.19)
D6 DIN PN100 9.04(4.10) 11.22(5.09) 13.92(6.31) N/A 21.01(9.53) 27.88(12.65)
