Reference Manual
00809-0100-4792, Rev CA
August 2010
3-13
Rosemount 1495, 1496
Line Size
Flange Rating 2 in. (50 mm) 2.5 in.(64 mm) 3 in. (80 mm) 4 in.(100 mm) 6 in.(150 mm) 8 in.(200 mm) 10 in.(250 mm)
ANSI Thickness = 0.375 in. (9.53 mm)
A3 ANSI Class 300 2.05(0.93) 2.66(1.21) 3.37(1.53) 4.75(2.16) 8.73(3.96) 13.49(6.12) 18.26(8.28)
A6 ANSI Class 600 2.05(0.93) 2.66(1.21) 3.37(1.53) 5.38(2.44) 9.82(4.45) 14.54(6.60) 22.09(10.02)
A6 ANSI Class 900 3.12(1.41) 4.02(1.83) 4.17(1.89) 6.05(2.74) 11.45(5.19) 17.96(8.15) 25.94(11.77)
AF ANSI Class 1500 3.12(1.41) 4.02(1.83) 4.45(2.02) 6.22(2.82) 10.97(4.97) 17.36(7.88) 25.94(11.77)
AT ANSI Class 2500 3.24(1.47) 4.16(1.89) 5.54(2.51) 7.71(3.50) 13.73(6.23) 20.77(9.42) 30.90(14.02)
DIN Thickness = 0.118 in. (4.0 mm)
D1 DIN PN10 1.06(0.48) 1.32(0.60) 1.55(0.70) 1.88(0.85) 3.06(1.39) 4.55(2.07) 6.39(2.90)
D2 DIN PN16 1.06(0.48) 1.32(0.60) 1.55(0.70) 1.88(0.85) 3.06(1.39) 4.55(2.07) 6.42(2.91)
D3 DIN PN25 1.06(0.48) 1.32(0.60) 1.55(0.70) 1.99(0.90) 3.21(1.46) 4.90(2.22) 6.84(3.10)
D4 DIN PN40 1.06(0.48) 1.32(0.60) 1.55(0.70) 1.99(0.90) 3.21(1.46) 5.09(2.31) 7.30(3.31)
D5 DIN PN63 1.13(0.51) 1.48(0.67) 1.64(0.74) 2.11(0.96) 3.81(1.73) 5.72(2.60) 7.77(3.52)
D6 DIN PN100 1.21(0.55) 1.58(0.72) 1.74(0.79) 2.23(1.01) 4.09(1.86) 6.25(2.84) 8.90(4.04)
Line Size
Flange Rating 12 in.(300 mm) 14 in.(350 mm) 16 in.(400 mm) 18 in.(450 mm) 20 in.(500 mm) 24 in.(600 mm)
ANSI Thickness = 0.375 in. (9.53 mm)
A3 ANSI Class 300 24.50(11.11) 32.11(14.56) 39.41(17.88) 47.49(21.54) 56.87(25.80) 79.51(36.07)
A6 ANSI Class 600 28.56(12.95) 16.20(7.35) 43.12(19.56) 50.01(22.68) 61.89(28.07) 82.78(37.55)
A6 ANSI Class 900 33.76(15.31) 36.75(16.67) 44.55(20.21) 54.18(24.57) 64.77(29.38) 92.97(42.17)
AF ANSI Class 1500 36.75(16.67) 45.03(20.43) 55.25(25.06) 65.94(29.91) 75.68(34.33) 108.25(49.10)
AT ANSI Class 2500 40.78(18.50) N/A N/A N/A N/A N/A
DIN Thickness = 0.157 in. (4.0 mm)
D1 DIN PN10 8.34(3.79) 11.05(5.01) 13.68(6.20) 16.53(7.50) 20.10(9.12) 27.31(12.39)
D2 DIN PN16 8.59(3.90) 11.35(5.15) 14.01(6.35) 17.50(7.94) 21.64(9.81) 30.40(13.79)
D3 DIN PN25 9.30(4.22) 12.00(5.44) 15.07(6.84) 18.11(8.22) 22.13(10.04) 30.16(13.68)
D4 DIN PN40 10.07(4.57) 12.88(5.84) 16.94(7.68) 18.49(8.39) 22.39(10.16) 31.47(14.27)
D5 DIN PN63 10.39(4.71) 13.51(6.13) 16.77(7.61) N/A 24.47(11.10) 32.89(14.92)
D6 DIN PN100 12.05(5.47) 14.96(6.79) 18.56(8.42) N/A 28.01(12.71) 37.17(16.86)
Line Size
Flange Rating 2 in. (50 mm) 2.5 in.(64 mm) 3 in. (80 mm) 4 in.(100 mm) 6 in.(150 mm) 8 in.(200 mm) 10 in.(250 mm)
ANSI Thickness = 0.500 in. (12.70 mm)
A3 ANSI Class 300 2.74(1.24) 3.55(1.61) 4.49(2.04) 6.34(2.87) 11.64(5.28) 17.99(8.16) 24.35(11.04)
A6 ANSI Class 600 2.74(1.24) 3.55(1.61) 4.49(2.04) 7.17(3.25) 13.09(5.94) 19.39(8.80) 29.45(13.36)
A6 ANSI Class 900 4.16(1.89) 5.37(2.43) 5.55(2.52) 8.07(3.66) 15.26(6.92) 23.94(10.86) 34.58(15.69)
AF ANSI Class 1500 4.16(1.89) 5.37(2.43) 5.94(2.69) 8.30(3.76) 14.62(6.63) 23.15(10.50) 34.58(15.69)
AT ANSI Class 2500 4.32(1.96) 5.55(2.52) 7.39(3.35) 10.29(4.67) 18.31(8.31) 27.70(12.56) 41.20(18.69)
DIN Thickness = 0.118 in. (6.0 mm)
D1 DIN PN10 1.59(0.72) 1.98(0.90) 2.32(1.05) 2.83(1.28) 4.59(2.08) 6.83(3.10) 9.58(4.35)
D2 DIN PN16 1.59(0.72) 1.98(0.90) 2.32(1.05) 2.83(1.28) 4.59(2.08) 6.83(3.10) 9.64(4.37)
D3 DIN PN25 1.59(0.72) 1.98(0.90) 2.32(1.05) 2.99(1.35) 4.82(2.18) 7.35(3.33) 10.26(4.65)
D4 DIN PN40 1.59(0.72) 1.98(0.90) 2.32(1.05) 2.99(1.35) 4.82(2.18) 7.35(3.46) 10.26(4.96)
D5 DIN PN63 1.70(0.77) 2.22(1.01) 2.46(1.12) 3.16(1.43) 5.71(2.59) 8.59(3.89) 11.66(5.29)
D6 DIN PN100 1.82(0.83) 2.37(1.07) 2.61(1.18) 3.34(1.51) 6.14(2.78) 9.38(4.25) 13.35(6.05)
