Maintenance
Figure 4-1. Models 3144 and 3244MV
Exploded View.
Figure 4-2. Electronics Module.
LCD Meter
Electronics
Module
Housing with
Permanent
Terminal Block
Nameplate
Cover with Wiring
Diagram Label
Extended Cover
3144-0001B01B
Security Jumper
Failure Mode Jumper
(without a Meter Installed)
3144-0201G01A
