Rosemount Models 3144 and 3244MV Smart Temperature Transmitters
5-12
ORDERING INFORMATION
TABLE 1. Model 3144 and 3244MV Ordering Information. (• = Applicable, — = Not Applicable)
Model Product Description 3144 3244MV
3244MV Smart Temperature Transmitter with Dual-Sensor Input — •
3144 Smart Temperature Transmitter • —
Code Transmitter Mounting Type
D Dual-Compartment Field Mount Transmitter (Model 3144 Only) • —
Code Housing Conduit Thread
1 Aluminum
1
/2–14 NPT ••
2 Aluminum M20 3 1.5 (CM20) ••
3 Aluminum PG13.5 (PG11) ••
4 Aluminum JIS G
1
/2 ••
5StainlessSteel
1
/2–14 NPT ••
6 Stainless Steel M20 3 1.5 (CM20) ••
7 Stainless Steel PG13.5 (PG11) ••
8 Stainless Steel JIS G
1
/2 ••
Code Hazardous Locations Certifications
E5 FM Explosion-Proof Approval ••
K5 FM Intrinsic Safety, Non-Incendive and Explosion-Proof Approval Combination ••
KB FM and CSA Intrinsic Safety and Explosion-Proof Combination ••
C6 CSA Intrinsic Safety, Non-Incendive and Explosion-Proof Approval Combination ••
E9 ISSeP/CENELEC Flameproof Approval ••
N1 BASEEFA Type N Approval ••
I1 CENELEC/BASEEFA Intrinsic Safety Approval ••
E7 SAA Flameproof Approval ••
N7 SAA Type N Approval ••
I7 SAA Intrinsic Safety Approval ••
IE CEPEL Intrinsic Safety Approval ••
E4 JIS Flameproof Approval; requires either Housing Code 4 (aluminum housing with JIS G
1
/2 conduit threads)
or Housing Code 8 (stainless steel housing with JIS G
1
/2 conduit threads).
••
NA No Approval ••
Other approvals available or pending. Call Rosemount Customer Central for more information.
Code Options
Accessory Options
B4 Universal Mounting Bracket for 2-inch Pipe and Panel Mounting—SST Bracket and Bolts ••
B5 Universal “L” Mounting Bracket for 2-inch Pipe Mounting—SST Bracket and Bolts ••
M5 LCD Meter ••
G1 External Ground Lug Assembly (See Table on page 5-9) ••
T1 Integral Transient Protector ••
Configuration Options
U1
Hot Backup
— •
U2 Average Temperature with
Hot Backup
and Drift Alert — •
U4 Two Independent Sensors — •
U5 Differential Temperature — •
U6 Average Temperature — •
C1 Factory Configuration of Date, Descriptor, and Message Fields (completed CDS 00806-0100-4724 required
with order)
••
C2 Trim to Specific Rosemount RTD Calibration Schedule (Sensor Matching) ••
C4 5-Point Calibration (Use Option Code Q4 to Generate a Calibration Certificate) ••
C7 Trim to Special Non-Standard Sensor (Special Sensor—Customer Must Provide Sensor Information), May
Be Used As Sensor Input for Either Sensor 1 or Sensor 2
••
F5 50 Hz Line Voltage Filter ••
A1 Analog Output Levels Compliant with NAMUR Recommendation NE-43, 27-June-1996 ••
CN Analog Output Levels Compliant with NAMUR Recommendation NE-43, 27-June-1996, Alarm
Configuration—Low
••
Note: NAMUR-compliant operation is pre-set at the factory and cannot be changed to standard operation in the field.
Assembly Options
X1 Assemble Transmitter to a Sensor Assembly (hand tight,
Te flon
(PTFE) tape where appropriate, fully wired) ••
X2 Assemble Transmitter to a Sensor Assembly (hand tight, no
Te f lo n
(PTFE) tape, unwired) ••
X3 Assemble Transmitter to a Sensor Assembly (wrench tight,
Te flo n
(PTFE) tape where appropriate, fully wired) ••
Note: Option codes X1 and X3 are not available with CSA approval.
