5-13
Specifications and Reference Data
Tagging
Hardware Tag
The transmitter will be tagged at no charge in accordance with
customer requirements. All tags are stainless steel. The standard
hardware tag is permanently attached to the transmitter. Tag
character height is
1
/16 inch (1.6 mm).
Software Tag
The transmitter can store a software tag up to eight characters in its
memory. The transmitter can be ordered with different software and
hardware tags. However, if the software tag characters are not
specified, the software tag will default to the first eight characters of
the hardware tag.
Standard Configuration (Models 3144 and 3244MV)
Unless specified, the transmitter will be shipped as follows:
All standard configuration settings may be changed in the field with a
HART communicator.
Calibration Certification Options
Q4 Calibration Certificate (3-Point standard; use C4 with Q4 option for a 5-Point Calibration Certificate) ••
Typical Model Number: 3244 MV 1 E5 B4 M5 U2
TABLE 1. Model 3144 and 3244MV Ordering Information. (• = Applicable, — = Not Applicable)
Model Product Description 3144 3244MV
Standard Configuration
Sensor Type 4-wire Pt 100 α = 0.00385 RTD
4 mA value 0 °C
20 mA value 100 °C
Damping 5 seconds
Output Linear with temperature
Failure Mode High
Line Voltage Filter 60 Hz
Software Tag See “Tagging” below
Integral Meter None (meter not installed)
Units and mA (meter installed)
3144 Standard Output Configuration
Primary Variable (4–20 mA) Sensor 1
Secondary Variable Terminal Temperature
Tertiary Variable Not Available
Quaternary Variable Not Available
3244MV Standard Output Configuration
Primary Variable (4–20 mA) Sensor 1
Secondary Variable Sensor 2
Tertiary Variable Terminal Temperature
Quaternary Variable Not Used
