Rosewill RNX-N150PCX - Product Specification; System Requirement

Wireless N Adapter RNX-N150PCx User Manual
1.4 Product
Specification
Standard
IEEE 802.11n Draft 2.0 and IEEE802.11g/b
RF Output Power(Typical)
802.11b: up to 17 ± 1 dBm
802.11g: up to 15 ± 1 dBm
802.11n: up to 16 ± 1 dBm
Driver Support
Windows® 2000, XP 32/64, Vista 32/64, Win7 32/64
Frequency Band
2.400GHz ~ 2.484GHz
Interface
PCI interface 2.2
Security
64/128-bit WEP (Hex & ASCII), WPA(TKIP with IEEE 802.1x),
WPA2(AES with IEEE 802.1x)
Dimension:
Without Bracket
120 x 80 x 15 mm
4.7 x 1.7 x 0.5 inches
With Bracket
4.7 x 4.7 x 1.7 inches
Data Rate
802.11n: up to 150Mbps Upstream and up to 150
Mbps downstream
802.11g: 54, 48, 36, 24, 18, 12, 9 & 6Mbps
802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall
back
Antenna
100 cm 2dBi External Detachable antenna
Weight: (with Bracket and Antenna)
45 g
Operation Temperature
0°C ~ 55°C ambient temperature
Storage Humidity
10% ~ 90% (Non-condensing)
Storage Temperature
-20°C ~ 70°C ambient temperature
1.5 System Requirement
You must have at least the following
 A desktop PC with an available 32-bit PCI slot
 Minimum 300MHz processor and 32MB memory
 Windows 98SE, ME, 2000, XP 32/64, Vista 32/64, Win7 32/64
 A CD-ROM Drive
 PCI controller properly installed and working in the desktop PC
 802.11n or 802.11b/g Access Point (for infrastructure Mode) or
another 802.11n or 802.11b/g wireless adapter (for Ad-Hoc;
Peer-to-Peer networking mode.)
- 10 -
