Wireless N Adapter RNX-N150PCx User Manual
Chapter 3 Installation Guide
3.1 Hardware Installation
To install the adapter, follow these steps listed below:
1. Turn off your desktop PC and disconnect the power.
2. Remove your PC case and locate an available PCI slot on the
motherboard. Remove the metal slot cover on the back of the PC.
Check with your computer manufacturer for instructions if needed.
3. Slide the PCI Adapter into the PCI slot. Make sure that all of its
pins are touching the slot's contacts. Once the adapter is firmly in
place, secure its fastening tab to your PC's chassis with a
mounting screw as shown in Figure 3-1. Then, close your PC
case.
Figure 3-1
4. Reconnect your PC’s power and turn on your desktop PC.
Note: Select Cancel when “Found New Hardware” window
appears.
- 13 -
