Wireless N Adapter RNX-N150PCx User Manual
Definition of Each Fields in Network:
SSID, Channel and Signal buttons: Click each button to sort
the listing networks by SSID, Channel and Signal strength.
Show dBm: Mark the checkbox to show the signal strength in
dBm.
Rescan: To rescan available wireless networks.
Connect: Click this button to connect to a designated network.
Add to Profile: Click this button to add a network to profile after
selecting a network.
5.1.3 Advance
Advanced configurations for this adapter.
Figure 5-7
Figure 5-8
Definition of Each Fields in Advance:
Wireless mode: Click the drop list to select a wireless mode.
Enable TX Burst: Select to enable connecting to a TX Burst
supported device.
Enable TCP Window Size: Mark the checkbox to enable TCP
window size, which help enhance throughput.
Fast Roaming at __ dBm: Mark the checkbox to enable fast
roaming. Specify the transmit power for fast roaming.
Show Authentication Status Dialog: Mark the checkbox to show
“Authentication Status Dialog” while connecting to an AP with
authentication. Authentication Status Dialog displays the
process about 802.1x authentication
Enable CCX (Cisco Compatible extensions): Select to enable
CCX. This function can only be applied when connecting to a
Cisco compatible device.
5.1.4 Statistics
Provides you with information on your wireless adapter.
Statistics displays the detail counter
information based on
802.11 MIB counters. This page translates the MIB counters
into a format easier for user to understand.
Figure 5-9
- 27 -
