5.3 Pressure washing
Caution:
When pressure washing the Refuse
Collection Vehicle, its chassis-cab, body,
refuse compaction mechanism and
any ancillary equipment, such as waste
container lifting devices, do not allow the
jet nozzle to approach closer than 1 metre.
Clean the compaction mechanism and slide tracks by
Pressure washing at least once a week as follows:
1. Stand the vehicle on clean, level and stable ground
with sufficient clearance to allow for the tailgate to
be fully raised.
2. Engage the parking brakes.
3. Select Neutral ‘N’.
4. Open the tailgate drains (see ‘5.1.2 Tailgate drains’
on page 5‑4).
5. Prop the tailgate (see ‘Operator’s Handbook’).
6. Turn the ‘Body main’ switch to the ‘off’ position.
Remove and retain the key.
7. Switch ignition ‘off’. Remove and retain the key.
8. Secure a sign ‘DO NOT START or OPERATE
VEHICLE’ to the steering wheel.
9. Lock all cab doors. Remove and retain the keys.
10. Using a proprietary pressure washer, clean the
compaction mechanism and ejection plate and
their slide blocks and tracks.
11. Inspect the seal and its mating face.
12. Unprop the tailgate (see ‘Operator’s Handbook’).
13. Close the tailgate drains (see ‘5.1.2 Tailgate drains’
on page 5‑4).
5.4 Cleaning the leachate tank
1 2
3
Fig. 5-3 Leachate Tank
1. Open ball valve drain.
2. Release leachate tank door catch.
3. Open leachate tank door.
4. Using proprietary pressure washer thoroughly
clean the inside of the leachate tank.
5. Ensure all liquid has drained from the leachate
tank.
6. Close the leachate tank door.
7. Close ball valve drain.
5.5 Cleaning the light curtain units
Clean the transmitter and receiver screens using a mild
detergent.
CLEANING
5‑6
OM1R-SM-GB01R
