RosRoca Olympus Mini - Slide Block Checks

SCHEDULED MAINTENANCE
6‑14
OM1R-SM-GB01R
6.9.5 Slide block checks
1. Check condition of ejection plate slide blocks (1).
• The maximum wear allowed for any of each
slide block’s dimensions is 6 mm.
2. Check condition of carriage plate slide blocks (2).
• The maximum wear allowed for any of each
slide block’s dimensions is 6 mm.
4730-OM1-R-GB-G1
1
2
6
