2. Technical Specifications
This chapter discusses the technical specification required for the system.
2.1 Panel
Electrical Characteristics
Operating Voltage
12 VDC 0.5 A (from PS-14)
Maximum Input Current
(not including attached devices)
Standby: 125 mA
Maximum: 325 mA
Relay Outputs
5 A Relay N.O. and N.C. options
General Inputs
High impedance active low inputs.
Maximum voltage: 5 VDC
Reader's Electrical Requirements
Voltage: 12 VDC
Max current: 300 mA
Visual
8 on
board LEDs as well as three PS LEDs (power,
low battery, output (V) Fail)
Audio
Built-in sounder (bell, chime and siren)
Speaker's Electrical
Characteristics
8 Ohm, 250 mW
Environmental Characteristics
Operating Temperature Range
0°C to 49°C (32°F to 120.2°F)
Operating Humidity Range
0 to 85% (non-condensing)
Dimensions
Enclosure (L x W x D)
264 x 334 x 84.5 mm (10.4 x 13.2 x 3.4 in.)
Weight
3.8 kg (8.3 lb)
2.2 Transformer
AC-215
Input: 120/220 VAC
Output: 16 VAC 2.5 A (40 VA) supplied, internal
to unit
AC-215U
Input: 120 VAC
Output: 16.5 VAC 2.42 A (40 VA) Class 2 (not
included). Use wall plug-in unit such as Universal
Power Group Part No. UB1640W.
