Rosslare AC-215 Hardware Installation Manual

Wiring
28 AC-215 Installation Manual
6.3.1 Power Supply
Figure 9 illustrates wiring between the PS-14 power supply and the AC-215. It
is recommended to add a 12 VDC lead acid backup battery to backup power if
the main fails.
If the main output is 12 VDC, wire it to the (PS-14); otherwise support your
power supply according to output requirements.
Figure 9: AC-215 Wiring to Power Supply

Rosslare AC-215 Specifications

General

Brand	Rosslare
Model	AC-215
Category	Gateway
Language	English
