DIP Switch Settings Configuration
AC-215 Installation Manual 19
4.3 ACU Addressing
The DIP switch is used to select the binary coded ACU address.
The ACU address is defined in the AxTraxNG software. For successful
communications, the dipswitch must be defined with the same address.
Table 4 displays the 32 address settings available:
Table 4: Available Panel Addresses
Address Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
1
Off Off Off Off Off
2
Off Off Off Off On
3
Off Off Off On Off
4
Off Off Off On On
5
Off Off On Off Off
6
Off Off On Off On
7
Off Off On On Off
8
Off Off On On On
9
Off On Off Off Off
10
Off On Off Off On
11
Off On Off On Off
12
Off On Off On On
13
Off On On Off Off
14
Off On On Off On
15
Off On On On Off
16
Off On On On On
17
On
Off Off Off Off
18
On
Off Off Off On
19
On
Off Off On Off
20
On
Off Off On On
21
On
Off On Off Off
22
On
Off On Off On
23
On
Off On On Off
24
On
Off On On On
25
On On
Off Off Off
1 2 3 4 5 6 7 8
