When connecting a reader, the following should be defined:
Scenario Setting
Two Readers per Door
Door 1 – Reader 1 IN/OUT
Door 1 – Reader 2 IN/OUT
Door 2 – Reader 3 IN/OUT
Door 2 – Reader 4 IN/OUT
Door 3 – Reader 5 (OSDP) IN/OUT
Door 3 – Reader 6 (OSDP) IN/OUT
One Readers per Door
Door 1 – Reader 1 IN/OUT
Door 2 – Reader 2 IN/OUT
Door 3 – Reader 3 IN/OUT
Door 4 – Reader 4 IN/OUT
Door 5 – Reader 5 (OSDP) IN/OUT
Door 6 – Reader 6 (OSDP) IN/OUT
When using the D-805, the following should be defined:
Scenario Setting
Two readers per door:
Door 1 – Reader 1 IN/OUT
Door 1 – Reader 2 IN/OUT
Door 2 – Reader 3 IN/OUT
Door 2 – Reader 4 IN/OUT
Door 3 – Reader 5 (OSDP) IN/OUT
Door 3 – Reader 6 (OSDP) IN/OUT
Door 4 – Reader 1D IN/OUT
Door 4 – Reader 2D IN/OUT
Door 5 - Reader 3D IN/OUT
Door 5 - Reader 4D IN/OUT
One reader per door:
Door 1 – Reader 1 IN/OUT
Door 2 – Reader 2 IN/OUT
Door 3 – Reader 3 IN/OUT
Door 4 – Reader 4 IN/OUT
Door 5 – Reader 5 (OSDP) IN/OUT
Door 6 – Reader 6 (OSDP) IN/OUT
Door 7 – Reader 1D IN/OUT
Door 8 – Reader 2D IN/OUT
Door 9 – Reader 3D IN/OUT
Door 10 – Reader 4D IN/OUT
