Use the AxTraxNG/AxTraxPro Access Control Management Software to set the readers for IN or OUT use and to set
the data transmission format for each reader.
The reader’s tamper output connects to the access control panel's Reader-Tamper input. If the reader is interfered
with, a trouble signal can be generated.
The controller activates the LED control for the time the door is open.
5. AC-825IP Hardware Settings
Access control panels, configured as either single reader door or double reader door controllers, have two readers, IN
or OUT.
Expansion boards attached to the expansion slot of the panel must be configured the same as the panel (single or
double door).
Expansion boards connected via RS-485 standard can be configured independently of the panel.
When configuring two readers per door, the two readers connected to a door must be using the same
format (OSDP or Wiegand).
Table 2: Possible Hardware Settings
Connectors Description Setup
Two Readers Per Door
Outputs
Door 1 Lock output (OUT 1)
Door 2 Lock output (OUT 3)
Door 3 Lock output (OUT 5)
General purpose output (OUT 2)
General purpose output (OUT 4)
General purpose output (OUT6)
Inputs
Door 1: Request-to-Exit (IN 1A)
Door monitor input (IN 1B)
Door 2: Request-to-Exit (IN 3A)
Door monitor input (IN 3B)
Door 3: Request-to-Exit (IN5A)
Door monitor input (IN5B)
Readers
Reader1 – Door1 Door Entry or Exit
Reader2 – Door1 Door Exit or Entry
Reader3 – Door2 Door Entry or Exit
Reader4 – Door2 Door Exit or Entry
Reader5 (OSDP) – Door3 Door Exit or Entry
Reader6 (OSDP) – Door3 Door Exit or Entry
