Rosslare AC-825IP Installation & User Guide

Connectors Description Setup
One Reader Per Door
Outputs
Door1 Lock output (OUT 1)
Door2 Lock output (OUT 2)
Door3 Lock output (OUT 3)
Door4 Lock output (OUT 4)
Door5 Lock output (OUT 5)
Door6 Lock output (OUT 6)
Inputs
Door1 Request-to-Exit (IN 1A)
Door monitor input (IN 1B)
Door2 Request-to-Exit (IN 2A)
Door monitor input (IN 2B)
Door3 Request-to-Exit (IN 3A)
Door monitor input (IN 3B)
Door4 Request-to-Exit (IN 4A)
Door monitor input (IN 4B)
Door5 Request-to-Exit (IN 5A)
Door monitor input (IN 5B)
Door6 Request-to-Exit (IN 6A)
Door monitor input (IN 6B)
Readers
Reader1 (Door1 IN/OUT)
Reader2 (Door2 IN/OUT)
Reader3 (Door3 IN/OUT)
Reader4 (Door4 IN/OUT)
Reader5 (Door5 IN/OUT)
Reader6 (Door6 IN/OUT)
Two Readers Per Door With 10 Readers (D-805)
Outputs
Door1 Lock output (OUT 1)
Door2 Lock output (OUT 3)
Door3 Lock output (OUT 5)
Door4 Lock output (OUT 1D)
Door5 Lock output (OUT 3D)
AC-825IP Installation & User Guide
www.rosslaresecurity.com
34

Rosslare AC-825IP Specifications
