The onboard Ethernet TCP/IP was evaluated by UL as a standalone unit and is used for programming use
only.
The AC-825IP platform consists of the following components:
•
AC-825IP networked access controller
•
ME-1515 metal enclosure with a detachable illumination bar
•
Up to 4 A power management board
•
VAC/VDC power switch
•
Terminal block removal tool
•
12 x 2.2 kΩ and 12 x 8.2 kΩ resistors for the supervised inputs
1.1. Open Supervised Device Protocol
OSDP allows connecting control panels with various peripheral devices (card readers, control panels, and other
security management systems) while unlocking the potential of the onboard computing resources within the system.
Any device that is connected to the AC-825IP panel via RS-485 must have a unique serial address.
1.1.1. OSDP-SC
The AC-825IP supports SIA Open Supervised Device Protocol (OSDP V2) including OSDP-SC (secure channel).
OSDP-SC is configured with the AxTraxPro Access Control Management Software.
AxTraxPro only supports the AC-825IP controller with VG MCU.
1.2. Compatible Readers
The AC-825IP access control unit provides support for most of the Wiegand formats, such as 26-bit, 30-bit, 32-bit, 35-
bit, and 36-bit, as well as any OSDP readers that may be connected serially to the AC-825IP via RS-485 interface.
Supports UL Listed Rosslare readers. UL Listed OSDP readers should be used with the OSDP port of the
AC-825IP.
1.3. Compatible Peripheral Devices
The AC-825IP is compatible with peripheral devices that support SIA standard OSDP V1, OSDP V2 (including secure
channel).
AC-825IP Installation & User Guide
www.rosslaresecurity.com
2
