AC-F/G4x Family Installation and Programming Manual 13
2. Technical Specifications
AC-F43 AC-F44 AC-G43 AC-G44
Input
Voltage*
VDC
12 to 24 VDC
VAC
16 to 24 VAC
Maximum Input Current
(12 VDC)
125 mA 160 mA 125 mA 160 mA
Standby Input Current
(12 VDC)
75 mA 95 mA 75 mA 95 mA
Maximum Relay Current
2 A
REX Input
Normally Open (dry contact)
Aux. Input
Normally Open (dry contact)
Max. Proximity Read
Range
N/A 75 mm
(2.95 in.)
N/A 80 mm
(3.15 in.)
Proximity Modulation
N/A ASK at125
KHz
N/A ASK at 125
KHz
Proximity Card
Compatibility
N/A 26 Bits EM
cards
N/A 26 Bits EM
cards
LED Indicators
Two 3-colored LED (Mode and Door)
Operating Temperatures
-22°F to 150°F (-30°C to 65°C)
Operating Humidity
0 to 95% (non-condensing)
Outdoor Usage
Weather resistant, meets IP-65, Epoxy potted
Size (H x W x D)
120.9 x 71.1 x 29.7 mm
(4.72 x 2.80 x 1.17 in.)
135.4 x 44.2 x 28.5 mm
(5.33 x 1.74 x 1.12 in.)
Weight
0.54 lb (244 g) 0.39 lb (178 g)
* All input voltages should be limited to 1 A maximum. For VAC, the
voltage range is peak-to-peak.
