Programming
48 AC-F/G4x Family Installation and Programming Manual
5.13.2 Relay Code Assignment using Search Method
To assign the relay code using Search method:
1. Enter Programming mode.
2. Press 9 to enter Menu 9.
The Mode indicator turns green.
The Door indicator turns orange
3. Enter 000 for user slot access.
The Door indicator flashes orange.
The controller is now waiting for the primary code of the user.
4. Enter the primary code belonging to the user.
The Mode indicator flashes green.
5. Enter the assignment digit for the current user slot:
1 activates the Lock Strike relay only deafult
2 activates the Auxiliary relay only
3 activates the Lock Strike and Auxiliary relays
If the assignment digit is valid, three beeps are heard and the
controller returns to Normal mode.
If the assignment digit is invalid, a long beep sounds and the
controller waits for another assignment digit to be entered.
