REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX DD2
Edition 2 / Rev. 0
Chapter 1
Page 14
September 01/2011
Power transmission from centrifugal clutch
to the rear axle of the kart
Roller chain
Chain dimension 7.75 x 4.6 x 4.5
Number of teeth of the drive sprocket 11, 12, 13, 14, 15, 16 teeth
Weight (dry) approx. 12 kg
without intake silencer, carburetor, fuel pump, radiator, exhaust
and battery.
Engine Type
125 MAX/125 Junior MAX/
125 Mini MAX/125 Micro MAX
