Rotax 125 Max - Cylinder System Description

DK00026.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 4
Page 3
December 01/2010
1) System description
Overview Position on the engine
Figure 1
K00010
Part Function
1 Cylinder
2 Cylinder head cover
3 Carburetor flange
4 Exhaust valve
1
2
3
4
