Rotax 125 Max - Disassembly of Carburetor

DK00028.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 6
Page 8
December 01/2010
2.1.2) Disassembly of carburetor
Carburetor See Figure 4.
Graphic Carburetor
Figure 4 K00064
Step Procedure
1 Disassemble the carburetor to the parts shown in Figure 4 and clean with fuel.
Needle Position
