Step Step Description Procedure
2 Set Throttle valve as
required
Set linearized throttle position
so that the engine speed is ap-
prox 2000 rpm.
Example (Symbolic) Set Throttle
3 Deactivate Fuel
pump 1
HIC A: Disconnect Terminal 3
and Terminal 9 to deactivate
Fuel pump 1
Example (Symbolic) Fuel pump 1: OFF
4 Observe Fuel pressure
Example (Symbolic) Pilot Display: Check
ATTENTION
If the fuel pressure is not within the limits, the cause must be deter-
mined. The engine must not be put into service until the problem is
rectified.
Step Step Description Procedure
5 Activate Fuel pump 1 HIC A: Disconnect Terminal 3
and Terminal 9 to deactivate
Fuel pump 1
Example (Symbolic) Fuel pump 1: OFF
6 Deactivate Fuel
pump 2
HIC A: Disconnect Terminal 3
and Terminal 11 to deactivate
Fuel pump 2
Example (Symbolic) Fuel pump 2: OFF
7
Observe Fuel pressure
Example (Symbolic) Pilot Display: Check
ATTENTION
If the fuel pressure is not within the limits, the cause must be deter-
mined. The engine must not be put into service until the problem is
rectified.
Step Step Description Procedure
8 Activate Fuel pump 2 HIC A: Disconnect Terminal 3
and Terminal 11 to deactivate
Fuel pump 2.
