NOTE
The ECU needs to deactivated first. Shutting of the engine by
deactivating the fuel supply may result in fault and failure en-
tries in the ECU. Shutting down the engine by shutting of the
fuel pumps is only allowed in emergency situations.
Step Step Description Procedure
5 Deactivate Fuel pumps HIC A: Disconnect Terminal 3 and
terminal 9 to turn OFF Fuel pump 1
HIC B: Disconnect Terminal 3 and
terminal 11 to turn OFF Fuel pump
2
Example (Symbolic) Fuel pump 1: OFF
Fuel pump 2: OFF
Page 3-20
December 01 2017
BRP-Rotax Effectivity: 915 i A Series
Edition 0 / Rev. 0
