71-00-00
page 4
May 01/2007
Effectivity 912/914 Series
Edition 1 / Rev. 0
d02621
BRP-Rotax
Maintenance Manual
2.2) Type description
e.g. ROTAX 914 F 2
â—† NOTE: The type description is composed as follows:
Type
(type)
Zulassung
(certification)
Baureihe
(configuration)
ROTAX
Type: 914 4-cylinder horizontally opposed turbo engine
Certification: F certified in accordance with FAR/ JAR-E (TW10 - ACG)
UL noncertified aircraft engines
Series 2: Propeller shaft with flange for fixed pitch propeller
3 : Propeller shaft with flange for variable pitch propeller and
drive for hydraulic controlled constant speed propeller
governor.
4 : Propeller shaft with flange for fixed pitch propeller but
prepared for retro-fitting of hydraulic controlled constant
speed propeller.
â—† NOTE: The propeller flange and hub are the same on all three gearbox
versions.
â—† NOTE: For the exact type description, see the latest Operators Manual
for your specific engine.
02091
