Rotex HPSU compact 304 Installation And Maintenance Manual

2 x Safety
FA ROTEX HPSU compact 4 - 06/2015
5
2Safety
2.1 Observing instructions
This instruction is the >> Original Version << in your language.
Please read this manual carefully and thoroughly before pro-
ceeding with the installation or modification of the heating
system.
These instructions are aimed at people who are authorised and
who have successfully completed a qualifying technical or skilled
manual training program for the particular work to be carried out
and who have participated in professional development seminars
recognised by the appropriate responsible authority. This, in par-
ticular, includes heating specialists and
climate control techni-
cians who have experience, as a result of their technical training
and their knowledge of the subject, of proper and appropriate in-
stallation and maintenance of heating, climate control and
co
oling installations and heat pumps.
This manual provides all the necessary information for instal-
lation, start-up and maintenance, as well as basic information on
operation and settings. All parameters needed for trouble-free
operation have been configured at the factory. Please go through
the attached documents for a detailed description of operation
and control.
Relevant documents
– ROTEX HPSU compact:
– Operating instructions for the user/owner
– Commissioning checklist
– The operating manual for the user/owner
– Operating instructions for the RoCon HP control unit
– External unit for ROTEX HPSU compact; the associated
inst
allation and operating instructions.
– When connecting to
a ROTEX solar system; the associated
installation and operating instructions.
– If a ROTEX HP convector is con
nected; the associated instal-
lation and operating instructions.
– In the case of connection to a control component offered as
an accessory (room controller, mixer module etc.); the asso-
ciated installation and operating instructions.
The guides are included in the scope of supply for the individual
units.
2.2 Warning signs and explanation of symbols
2.2.1 Meaning of the warnings
Warnings in this manual are classified according into their se-
verity and probability of occurrence.
DANGER!
Draws attention to imminent danger.
Disregarding this warning can lead to serious injury or
d
eath.
WARNING!
Indicates a potentially dangerous situation.
Disregarding this warning can result in serious injury
o
r death.
CAUTION!
Indicates a situation which may cause possible
damage.
Disregarding this warning can lead to damage to
property and the environment.
This symbol identifies user tips and particularly useful
information, but not warnings or hazards.
Special warning signs
Some types of danger are represented by special symbols:
Electric power
Risk of burning or scalding
Risk of environmental damage
Danger of local freezing up
Health impairing or irritant materials
Prescribed temperature for continuous use
Danger of explosion
2.2.2 Validity
Some information in this manual has limited validity. The validity
is highlighted by a symbol.
Exterior heat pump unit RRLQ
Heat pump indoor unit HPSU compact
HP convector
Only valid for ROTEX HPSU compact with cooling
function (see also section 2.4)
Pay attention to the stipulated tightening torque (See
chapter 10.3 "Tightening torque")
Only applicable for the unpressurised solar system
(drain-back)
Only applicable for the pressurised solar system.
2.2.3 Order number
References to order numbers can be recognised from the goods
symbol
.
