66
FA ROTEX HPSU compact 4 - 06/2015
10 x Technical data
10.2 Characteristic lines
10.2.1 Sensor characteristic lines
Refrigerant circuit
Number of circuits — 1
Pipe connections
Number — 2
Liquid line
Type — Flanged connection
External Ø inches 1/4" AG 3/8" AG 1/4" AG 3/8" AG
Gas lines
Type — Flanged connection
External Ø inches 5/8"
AG
Operating data
Operating range
Flow temperature
for room
heat-
ing/cooling function
Heating
(m
in/max)
°C
15 to 55
Cooling
(min/max)
°C 5 to 22
Hot water genera-
tion (with BUxx)
Heating
(m
in/max)
°C 25 to 80
Noise level
Audibility dBA 42 46 42 46
Noise pressure
2)
dBA 28 32 28 32
Electrical data:
Voltage supply
Phases — 1
Voltage V 230
Voltage range V Voltage ±10%
Frequency Hz 50
Mains connection
3)
Exterior heat pump unit for HPSU
compact
—
4G
External unit for heat pump — 3G 3G / 5G 3G 3G / 5G
Optaionl auxiliary
he
ating
Backup Heater
(BUxx)
— 3G (1-phase) / 5G (3-phase)
Order number
Heating/cooling function 14 15 32 14 15 33 14 15 36 14 15 37
Heating function only 14 15 41 14 15 38 14 15 44 14 15 45
* Not all the equipment mentioned here is offered in some
countries because of the various different country-specific
connection conditions.
1) T
CW
Cold water input temperature = 10 °C 
T
DHW
Hot water draw-off temperature = 40 °C 
T
S
Storage target temperature 
(charge state before drawing off)
2) With a reference spacing of 1 m.
3) Number of individual wires in the connection cable,
including protective
earth. The cross-section of the individual lines is dependent on the current
load, the length of the connection cable and the respective legal provi-
sions.
4) Hot water storage tank only to be charged using a heat pump, without a
backup heater.
Tab.
10-2 Basic data ROTEX HPSU compact 508/516
Type ROTEX HPSU compact
508 DB 516 DB 508 BIV 516 BIV
Temperature sensor
Measured temperature in °C
-20-100 102030405060708090100110120
Sensor resistance in kOhm according to standard or manufacturer's indications
t
DHW2
NTC
— — 811.5 480.6 293.2 183.8 118.2 77.7 52.3 35.8 25.1 17.8 12.9 9.5 7.1
t
Au
(RoCon OT1),
t
DHW1
NTC
98.66 56.25 33.21 20.24 12.71 8.20 5.42 3.66 2.53 1.78 1.28 0.93 0.69 0.52 0.36
t
Au
(R1T) NTC
197,8 112,0 65,8 40.0 25.0 16.1 10.6 7.2 5.0 3.5 2.5
——— —
t
V1
, t
V2
, t
V, BH
,
t
R2
NTC
197.80 120.00 65.84 39.91 24.95 16.04 10.58 7.14 4.77 3.19 2.36 1.74 1.33 1.07 0.84
