10 x Technical data
FA ROTEX HPSU compact 4 - 06/2015
65
10.1.2 ROTEX HPSU compact 508/516
Type ROTEX HPSU compact
508 DB 516 DB 508 BIV 516 BIV
Can be used with an external heat pump unit
RRLQ006CA
V
3/RRLQ008
CAV3
RRLQ011CA
(V3/W1)*/
RRLQ014CA
(V3/W1)*/
RRLQ016CA
(V3/W1)*
RRLQ006CA
V3/RRL
Q008
CAV3
RRLQ011CA
(V3/W1)*/
RRLQ014CA
(V3/W1)*/
RRLQ016CA
(V3/W1)*
Dimensions and weights Unit
Dimensions (H x W x D) cm 195 x 79 x 79
Empty weight kg 114 116 119 121
Main components
Water heat circula-
tion pump
Type Grundfos UPM2 15-70 CES87
Speed rates Continuously variable (PWM)
Voltage V 230
Frequency Hz 50
Protection type IP 42
Maximum rated output W 45
Heat exchanger
(water/coolant)
Type Stainless steel underfloor heat exchanger
Heat insulation
EPP
Storage tank
Total storage capacity litres 500
Maximum permissible storage water temperature °C 85
Heat consumption at stand-by and at 60 °C kWh/24h 1.4
Domestic water heat
exchan
ger (stainless
steel 1.4404)
Water capacity heat exchanger litres 29
Maximum operating pressure bar 6
Domestic water heat exchanger sur-
face
m
2
6.0
Storage tank charg-
ing heat exchanger
(stai
nless steel
1.4404)
Water capacity heat exchanger litres 12.1 17.4 12.1 17.4
Heat exchanger surface area m
2
2.5 3.5 2.5 3.5
Pressurised solar
hea
t exchanger
(stainless steel
1.4404)
Water capacity heat exchanger litres 12.5
Heat exchanger surface area m
2
—1.7
Thermal perfor-
mance data
1)
Hot water quantity without re-heating
at a flow rate of 8 l/min (12 l/min)
(T
S
=50 °C)
litres
364 (318)
32
8
4)
(276
4)
)
324 (282)
2
88
4)
(240
4)
)
Hot water quantity without re-heating
at
a flow rate of 8 l/min (T
S
=60 °C)
litres 540 (494) 492 (444)
Hot water quantity without re-heating
at
a flow rate of 8 l/min (12 l/min)
(T
S
=65 °C)
litres 612 (564) 560 (516)
Re-heating rime with a draw-off quan-
tity of:
min140 l = 5820 Wh (Ø bathtub) 45 25 45 25
90 l = 3660 Wh (Ø shower draw-off
q
uantity)
30 17 30 17
Pipe connections
Cold and hot water inches 1" AG
Heating feed and return flow inches 1" IG
Solar connections
inches
1" IG
inches 3/4" IG + 1" AG
