Rotex HPSU compact 304 Installation And Maintenance Manual

50
FA ROTEX HPSU compact 4 - 06/2015
8 x Errors, malfunctions and messages
E9004 7H Fehler Durchfluss Flow sensor FLS
Water flow is too low or there is none at all. Minimum water flow
requi
red:
– operating mode "Heizen": 600 l/h
– operating mode "Kühlen": 840 l/h
– Automatic defrosting function ( ) active: 1020 l/h
Check the following items:
Ɣ All stop valves of the water circuit must be completely open.
Ɣ Optional water filters must not be contaminated.
Ɣ Hea
ting system must run within its operating range.
Ɣ Heating system and device-internal circulation pump must be
completely bled.
Ɣ On the controller
(rotary switch setting "Info" ) check
whether there is adequate water pressure (>0.5 bar).
Ɣ Check the function of the 3-way switching valve 3UVB1
(compare actual setting of 3UVB1 with BPV position
[Übersicht] displayed in the parameter).
Ɣ If th
is fault occurs during defrost operation in the operating
mode room heating or water heating? With optional backup
heater: check its power supply and fuses.
Ɣ Che
ck the fuses in the control housing of the ROTEX HPSU
compact (pump fuse (FU1) on circuit board A1P and printed
circuit board fuse (F1) on the RoCon BM1 circuit board).
Ɣ Che
ck flow sensor FLS for contamination and function, if
necessary clean, replace.
E9005 8F
Flow temperature
t
V, BH
>75 °C
Flow temperature sensor
t
V, BH
Flow temperature of the backup heater (t
V, BH
) is too high.
– Flow temperature sensor sending incorrect values. Tempera-
ture sensor or connecting cable defective.
Ɣ Check, replace.
– Contact problem A1P-bridge on X3A.
E9006 8H
Flow temperature
t
V, BH
>65 °C
Flow temperature sensor
t
V, BH
E9007 A1 Platine IG defekt Circuit board A1P
Communication between the heat pump exterior equipment and
hea
t pump interior equipment malfunctioning.
– Electromagnetic influences.
Ɣ Perform reset.
– Circuit board A1P defective.
Ɣ Re
place circuit board A1P.
E9008 A5
Coolant tempera-
ture outside of the
vali
d range
Temperature sensor (liq-
uid-side coolant) t
L2
No heat absorption at the plate heat exchanger.
Ɣ Check flow.
Ɣ If the flow is OK, then replace the coolant temperature sensor.
E9009 AA
STB-Fehler
Optional: STL Backup
Heater (BUxx)
Thermal protection switch (STB) on Backup Heater (BUxx) was
triggered.
Ɣ Check and unlock position of STL.
E9010 AC Bridge on board A1P
Bridge of connection socket "X21A" missing on board A1P.
Ɣ Plug
in strapping plug.
E9011 C0 Fehler Flowsensor Flow sensor FLS
Flow sensor FLS defective.
Ɣ Rep
lace flow sensor FLS.
E9012 C4
Fehler Vorlauffüh-
ler
Flow temperature sensor
t
V2
or t
V, BH
Measurement outside the permitted value range. Sensor or con-
nection cable defective.
Ɣ Check, replace.
E9013 E1 Platine AG defekt
Main board of the heat
pump exterio
r unit
– Main board in the heat pump exterior unit defective.
– Ventilator motor defective.
Ɣ Check, replace.
Code Malfunction /
Error messageg
Component/Designation Causes and possible error correction
Display Internal
