1 x Safety
BA ROTEX HPSU compact 4 - 09/2013
3
1Safety
1.1 Observing instructions
This instruction is the >> Original Version << in your language.
All the activities required for operation and setting the parameters
are described in this instruction manual. All parameters needed
for trouble-free operation have been configured at the factory.
● Please read through this manual carefully before operating
the heating system or before adjusting the settings for it.
● Ma
ke a note of the preset values before you make any
changes to the unit configuration.
● Comply strictly with warning instructions.
● In
stallation and all modifications / settings of the device not
described in this manual may be performed only by qualified
and authorised specialist heating technicians.
Relevant documents
– ROTEX HPSU compact:
– Installation and Operating Instruction Manual
– The operating manual for the user/owner
– ROTEX RoCon HP: Operating instructions of the controller
– External unit for ROTEX HPSU compact; the associated
inst
allation and operating instructions.
– With connection of a ROTEX Solaris solar system; the asso-
ciated installation and operating instructions.
– With connection of a ROTEX HP con
vectors; the associated
installation and operating instructions.
– If a ROTEX room controller is connected; the associated
install
ation and operating instructions.
The guides are included in the scope of supply for the individual
un
its.
1.2 Warning signs and explanation of symbols
1.2.1 Meaning of the warnings
Warnings in this manual are classified according into their se-
verity and probability of occurrence.
DANGER!
Draws attention to imminent danger.
Disregarding this warning can lead to serious injury or
d
eath.
WARNING!
Indicates a potentially dangerous situation.
Disregarding this warning can result in serious injury
o
r death.
CAUTION!
Indicates a situation which may cause possible
d
amage.
Disregarding this warning can lead to damage to
property and the environment.
This symbol identifies user tips and particularly useful
information, but not warnings or hazards.
Special warning signs
Some types of danger are represented by special symbols:
Electric power
Risk of burning or scalding
Risk of environmental damage
1.2.2 Validity
Some information in this manual has limited validity. The validity
is highlighted by a symbol.
Only valid for ROTEX HPSU compact with heating and
cooling function
Comply with the specified tightening torque 
(see installation and operating manual)
Only applicable for the unpressurised system 
(Drain Back)
Only applicable for the pressurised system
Valid/available only if a room regulator is connected
Valid/available only if a mixer module is connected
1.2.3 Order number
Notes related to order numbers are identified by the shopping
cart symbol
.
1.2.4 Handling instructions
● Instructions on actions are shown as a list. Actions of which
the sequential order must be maintained are numbered.
 Results of actions are identified with an arrow.
Entry into a setting procedure
Exit from a setting procedure
1.3 Avoid danger
The ROTEX HPSU compact is state-of-the-art and is built to meet
all recognised technical requirements. However, improper use
may result in serious physical injuries or death, as well as
property damage.
To avoid danger, only operate the ROTEX HPSU compact:
– As stipulated and in perfect condition,
– With an awareness of the safety and hazards involved.
This assumes knowledge and use of the contents of this manual.
WARNING!
This unit is not intended for use by persons (including
child
ren) with impaired physical, sensory or mental
faculties or persons with insufficient experience and/or
expertise unless supervised by a person responsible
for ensuring their safety or are given instruction by this
person on how to use the unit.
