6 x Parameter settings
6.8 Rotary switch setting: Time Program
Parameter Designation Access Setting range
Min / Max
Factory
setting
Increment
BE HF
Party With this operating mode we can set a one-off time
for the temporary heating time extension
of the internal heating circuit.
E E 00:00 - 06:00 00:00 1 h
Away With this operating mode we can set a one-off time for the temporary regulation to the param-
eterised absence temperature.
E E 00:00 - 06:00 00:00 1 h
Vacation The internal heating circuit provides continuous (24 h per day) regulation to the parameterised
absence temperature (parameter T-Reduced).
A calendar function can be used to enter a time
period for the absence.
E E Date on first
da
y
-
Date on last
da
y
- 1 Day
Holiday A calendar function can be used to enter a time period for presence. E E Date on first
da
y
-
Date on last
da
y
- 1 Day
HC Program 1 In this menu we can parameterise the 1st timer programme for the internal heating circuit.
3 switching cycles with a resolution of 15 minutes can be set. A separate entry for each week-
day is possible. Format: (on) hh:mm - hh:mm (off)
Also, the cycles can be parameterised from Monda
y to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E See
chap
ter 3.4.7
See
tab. 3-7
15 min
HC Program 2 In this menu we can parameterise the 2nd timer programme for the internal heating circuit.
3 switching cycles with a resolution of 15 minutes can be set. A separate entry for each week-
day is possible. Format: (on) hh:mm - hh:mm (off)
Also, the cycles can be parameterised from Monda
y to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E See
chap
ter 3.4.7
See
tab. 3-7
15 min
DHW Program 1 In this menu we can parameterise the 1st timer programme for hot water generation. 3 switch-
ing cycles with a resolution of 15 minutes can be
set. A separate entry for each weekday is
possible. Format: (on) hh:mm - hh:mm (off)
Also, the cycles can be parameterised from Monda
y to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E See
chap
ter 3.4.7
See
tab. 3-7
15 min
DHW Program 2 In this menu we can parameterise the 2nd timer programme for hot water generation. 3 switch-
ing cycles with a resolution of 15 minutes can be
set. A separate entry for each weekday is
possible. Format: (on) hh:mm - hh:mm (off)
Also, the cycles can be parameterised from Monda
y to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E See
chap
ter 3.4.7
See
tab. 3-7
15 min
Circulation Time In this menu we can parameterise a timer programme for the circulation pump. 3 switching cy-
cles with a resolution of 15 minutes can be set. A separate entry for each weekday is possible.
F
ormat: (on) hh:mm - hh:mm (off)
Also, the cycles can be parameterised from Monda
y to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E See
chap
ter 3.4.7
See
tab. 3-7
15 min
Tab. 6-10 Parameter in rotary switch setting "Time Program"
6.9 Rotary switch setting: Remote Param
Parameter Description Access Setting range
Min / Max
Factory
setting
Increment
BE HF
Bus - Scan Off: No function
On: Control checks which RoCon
devices are connected to the system using the CAN bus
lines. Devices that are detected are displayed with their type and data bus ID 
(For example: MM#8 = Mixer module with bus ID 8).
The selection and activation of a device with the r
otary switch switches the function of the 
control unit to that of the selected device (see chapter 3.4.9).
E E Off
On
Off -
No selection Activation switches to the local device. E E
-
Contr BM1/BE1 #X Activation switches to the HPSU comp
act with the bus ID X. E E -
Mix Valve #X Activation switches to the mixer module with the bus ID X (see section 6.12.1, parameter 
[HC Assignment]).
E E
-
Tab. 6-11 Parameter in rotary switch setting "Remote Param"
