IQ3 manual – Section: Weights 7
5. Weights
Standard Actuator only:
Actuator Size
Weight
kg (lbs)
IQ10 31 (68)
IQ12 31 (68)
IQ18 31 (68)
IQ19
54 (119)
IQ20
54 (119)
IQ25
54 (119)
IQ35
75 (165)
IQ40
145 (320)
IQ70
145 (320)
IQ90
160 (353)
IQ91
150 (331)
IQ95
160 (353)
Thrust Compensator only:
Actuator Size
Weight
kg (lbs)
IQ10-18 10 (22)
IQ19-25 16 (35)
IQ35 26 (57)
IQ40-95
200 (440)
Actuator and Thrust Compensator
combination:
Actuator Size
Weight
kg (lbs)
IQ10 41 (90)
IQ12 41 (90)
IQ18 41 (90)
IQ19
70 (154)
IQ20
70 (154)
IQ25
70 (154)
IQ35
101 (223)
IQ40
345 (760)
IQ70
345 (760)
IQ90
360 (793)
IQ91
350 (771)
IQ95
360 (793)
